OpenSC don't have programs with graphic interface, so all the operations must be performed with Terminal.

Card reader (#1615) 16. macOS installer 17. Add installer option to deselect tokend (#1607) 18. Make OpenSCToken available on 10.12+.

Testing installation

You may check if the reader and the smart card is recognized with the following command:

1) opensc-tool -l - this command lists all the readers that are plugged in the computer. It should show something like this:

2) opensc-tool -n - 1)with this command you may check if your card is recognized correctly. If it's OK, you should get message “ CardOS M4”. If you get an error, that finishes with “ Failed to connect to card : Unresponsive card ( correctly inserted?)”,most probably your card is not inserted correctly in your smart card reader.

Change PIN

The PIN code of the card can be changed from the Device Manager of Firefox or with the following command - pkcs15-tool --change-pin. The length of the PIN on Infonotary cards can from 4 to 16 symbols, that can contain letters and digits.

Unblock PIN

In case that Firefox ask you for PIN multiple times, most probably you've blocked your PIN. You can unblock it with the following command pkcs15-tool -u

Change SO-PIN

SO-PIN can be changed with following command - pkcs15-tool --change-pin -a ID, here the ID must be change with it's identifier. You can check by running the followingpkcs15-tool --list-pins. Part of the log must look like that:

Identifier of the SO-PIN is the text, which is against ID section. In this case the command for changing the SO-PIN is pkcs15-tool --change-pin -a 02

Displaying the content of the card

With the following command you may see all the objects on the smart card pkcs15-tool -D

Forbid OpenSC to work with a specific card

Cards that are labeled T&S DS/2048 of the manufacturer Bit4id, re not supported in OpenSC 12.0 and above, so if you want to use that kind of a card with CardOS card you will have to edit the configuration file of OpenSC. You must add the following after the row with „app default {“: Vector magic 1.18 keygen machine.

n Mac OS X the file is /Library/OpenSC/etc/opensc.conf, to open it with privileges to edit you must use the following command - sudo /Applications/TextEdit.app/Contents/MacOS/TextEdit /Library/OpenSC/etc/opensc.conf

In Linux the configuration file location is /etc/opensc/opensc.conf or in /etc/opnesc.conf

The same way you can forbid certain model smart cards from OpenSC. You must add analogical section in the configuration file with the following content:

With the command opensc-tool -a you can display the ATR of a card. A list with the drivers that are supported you can receive by entering opensc-tool --list-drivers

Test

In order to check if the certificate works correctly you can use this command - pkcs11-tool -lt --module opensc-pkcs11.so. This command will ask you to enter PIN of the card 'Please enter User PIN:'. The PIN won't be displayed on the screen even with start. Press Enter to confirm. You should get a message like this:

One-time Office licenses (also known as perpetual), such as Office 2019 Home & Business, Office 2019 Home & Student, Office 2016 Home & Business, Office 2016 Home & Student, and Volume License are not compatible with Office apps downloaded from the Mac App Store. These licenses can only be used with Office apps downloaded directly from Microsoft. Download Microsoft PowerPoint for macOS 10.13 or later and enjoy it on your Mac. ‎A qualifying Office 365 subscription is required for Word, Excel, PowerPoint and Outlook. The PowerPoint app gives you access to the familiar tool you already know. Power point (read only) I purchased powerpoint for mac, do I need office for it to work? You need to ask your admin to assign you a license. Navigate to PowerPoint of the top bar About PowerPoint. Then check if your PowerPoint application has been activated. For Office for Mac, you can have up to 25 licenses associated with the same Microsoft account: only one license for an Office 365 subscription and multiple one-time-use installs of Office for Mac Home and Student or Home and Business. Classic 2019 versions of Word, Excel, PowerPoint and Outlook; plus, additional OneNote features (features vary, visit aka.ms/onenote-office2019-faq) Microsoft support included for 60 days at no extra cost Licensed for home and commercial use. Lifetime License Only Mac $ 214.99 $ 199.99. How to get powerpoint on mac.

When this message is displayed - “Please press return to continue, x to exit”, you must press “x” and press Enter. In case there is some problems with the reader, the card or the certificate, the command will finished with the message “error” and a description of the problem. For instance if your PIN is blocked you will get message : “ error: PKCS11 function C_Login failed: rv = CKR_PIN_LOCKED (0xa4)' , and if the entered PIN is incorrect the message will be :'error: PKCS11 function C_Login failed: rv = CKR_PIN_INCORRECT (0xa0)'.

In versions of OpenSC before 0.13, in dependance of the content of the card, it is possible to receive an error below “Signatures (currently only RSA signatures)“ . In this case you will have to test if it work in other program, like Firefox.
